Fibre Optic Header Units
For use with the AquaBat Water Level Recorder
For use with the AquaBat Water Level Recorder
Water Services
Features
Battery Powered for Self Contained Operation
Protected Plastic Boot Cover for environment operation
1 x Fibre Optic Port
Bluetooth Connection Status LED
Options for Bluetooth & SDI-12
Network
Free application software -
Microsoft Accredited Driver
Easy Battery Replacement -
2 x AA Cells
2 Year Battery Life -
Longer depends upon use
Auto-power
Off - Protects for
accidentally leaving unit on
Battery Powered for Self Contained Operation
Protected Plastic Boot Cover for environment operation
1 x Fibre Optic Port
Bluetooth Connection Status LED
Options for Bluetooth & SDI-
Header Unit Connected
to
the PDA using Bluetooth
wireless network
the PDA using Bluetooth
wireless network
Fibre Optic Cable
Specifications
Fibre Optic Port
Fibre optic cable
Fibre optic cable
316 Stainless Steel or
better
2.2 mm External diameter -
1 mm diameter core plastic multi-mode
fibre Single mode fibre for long distance operations
2.2 mm External diameter -
Construction
High Impact Resistant
Plastic Case
Dimensions
L150 x W 90 x D 30 mm
-
Including protective case
Sealing
Spray resistant
Battery Type
9V PP3
Data Comms
Speed 38 Kb -
Fibre Optic link only
450Kb -
Bluetooth Cable Free Link
Operating Temp
-
20 to + 60 Deg C
Battery Life
Greater than 2 yrs -
500 downloads
Low voltage warning in
software
Battery
included as standard.
Synchronisation
Automatic clock
synchronisation via
host
Range
Typical
fibre
comms < 120 m
Bluetooth comms < 15 m
Bluetooth comms < 15 m
Bluetooth Device
The Header unit operates as the communications interface between the AquaBat water level logger and an external data storage/Configuration device. The device running the applications package can be anything such as a PDA, mobile phone or similar than can use the Microsoft Mobile Version 6 or greater operating system.
The Header unit operates as the communications interface between the AquaBat water level logger and an external data storage/Configuration device. The device running the applications package can be anything such as a PDA, mobile phone or similar than can use the Microsoft Mobile Version 6 or greater operating system.
Fibre optic Header
units for use
with the AquaBAT water level recorders
NP-HDR-Bluetooth
Status LED Operations
The operation of the Header unit from power on to communication to the AquaBat is shown visibly using a series of LED indicators mounted on the front panel.
The operation of the Header unit from power on to communication to the AquaBat is shown visibly using a series of LED indicators mounted on the front panel.
Fibre optic
port
port
Windows Mobile 6.0
enabled device.
enabled device.
Last updated: Nov 2010
Part No. HDR-Bluetooth
